Benefits:
Time-Saving: Eliminates repetitive manual selections by allowing users to save and reuse presets for beams, columns, welds, and other objects.
Accuracy: Reduces errors by ensuring the exact same selection set can be recalled at any time.
Consistency: Keeps model navigation structured with standardized presets that can be reused across project stages.
Ease of Communication: The Smart View function provides clear isolation of selected presets, making coordination with teammates easier during design reviews or fabrication checks.
The Smart_SelectDisplay Tool is an essential solution for Tekla Structures users, simplifying model management by combining preset-based selection with instant visualization. It ensures faster workflows, improved accuracy, and enhanced clarity across all project phases.
The Smart_SelectDisplay Tool is a Tekla Structures Tool designed to streamline the selection and display of model objects. By allowing users to create, manage, and isolate presets, it removes the hassle of repetitive selection tasks while providing quick access to critical elements within the model.
Key Features:
Preset-Based Selection:
Save groups of beams, columns, welds, or any model objects as presets for quick recall and reuse.
Add / Remove Items in Presets:
Flexibly update existing presets by adding new objects or removing outdated ones, ensuring selections always stay relevant.
Preset Management:
Create, rename, or delete presets easily, keeping your project organized and clutter-free.
Smart View Button (with Machine Learning): Instantly isolate or highlight any preset in the model using machine learning intelligence, which automatically understands context and priorities. This helps you focus only on what matters most for checks, modifications, or reviews, without manual filtering.
User-Friendly Interface:
Simple, intuitive controls designed to fit seamlessly into your Tekla Structures workflow, making adoption quick and hassle-free.
